Please click on the presentation for an overview of the updated conceptual Sediment Management Plan and the Detailed Impact Assessment Process.
Specific questions about the project or just want to know more? Please see our frequently asked question and answers for the following categories:
Please also view our previous presentation series (2022) on the Kingston Inner Harbour Sediment Management Project for additional details.
The overall goal of the Project is to reduce chemical risks posed by contaminated sediments to humans and ecological groups (e.g., fish, wildlife, turtles, and their food resources) to an acceptable level while ensuring the protection of wildlife habitats (e.g., shoreline turtle habitat), archaeological values (e.g., shipwrecks and cultural artifacts), infrastructure (e.g., harbour walls, underwater utilities), and recreational values. This will require remediation of some areas in the Kingston Inner Harbour, focusing on the sediment where most of the chemicals are found.
The goal of the Project is not divestiture, but rather to meet the federal government's commitment to manage contaminated sites in a responsible manner. The project follows the federal program, called the Federal Contaminated Sites Action Plan (FCSAP), which aims to reduce the environmental and human health risks and associated federal financial liabilities at known federal contaminated sites. The program uses a systematic process to evaluate sites under federal responsibility and make management decisions. Although not a goal of the project, any future property transfers related to the Kingston Inner Harbour would follow the federal circulation process (described in Treasury Board’s Directive on the Management of Real Property), where the property is first offered to other Federal Departments, Provincial Corporations, Municipalities and Indigenous groups for continued public purpose use.
Sediment is the soft solid material that lies under the water at the bottom of a harbour, lake, or stream. Similar to how soil can move with the wind and rain, sediment also moves and mixes over time from waves, water currents, or disturbance by people and animals.
Sediment contamination is the presence of chemicals in sediment at levels higher than they would normally be. Many chemicals are naturally occurring, so the presence of a chemical in sediment does not necessarily mean that contamination exists. If there is contamination (chemicals that are in the sediment in higher-than-normal amounts), it is not necessarily dangerous for people or wildlife. Determining if contaminated sediment is safe or not depends on the area, the types of chemicals, the amounts of these chemicals, and the site uses.
Past studies of water quality of the harbour have found that the water quality is good compared to provincial and federal guidelines designed to protect people and wildlife. The main concern is the contaminated sediment that may be harmful to people and wildlife.
The chemicals of concern in the sediment fall into a few main categories: metals, PAHs and PCBs.
We’ve heard concerns about disturbance of buried chromium in Kingston Inner Harbour (KIH) sediments. These concerns generally fall in the following three categories:
Physical Mixing - Sampling has shown that the surface sediments of KIH are well mixed such that chemicals like chromium, which are no longer being generated from nearby industry, are not consistently found in distinct isolated layers or depths. Sediment transport has caused these chemicals to be spread both horizontally and vertically over time. Dredging programs use controls to limit further mixing and prevent chemicals from spreading downstream as they are removed. The Project design also includes adding cleaner materials to dredged areas to help reduce risks from newly exposed sediment layers. Keep in mind, mixing occurs naturally in the harbour without dredging. Over many years, natural processes like water movement and wildlife burrowing have moved and mixed sediments over many decades to result in the current patterns of sediment contamination. It is those same processes that caused contaminants to be spread broadly throughout the harbour in the past, well beyond the areas where they were originally introduced.
Current Chromium Speciation - While chromium can exist in different forms that affect how it moves into organisms or causes harm, the data show that in KIH, over 99% of the chromium in all layers is in a stable form called trivalent chromium (Cr-III). The sediment profiles show that elevated levels of chromium are found throughout sediment profile, including at the surface. There is no deep layer of harmful hexavalent chromium (Cr-VI) that would be exposed during dredging. The sediments in KIH are a mix of layers rather than separate, stable layers, and this natural mixing has kept chromium in a trivalent form throughout the upper sediment layers.
Chemical Transformation Potential - Layers of sediment with hexavalent chromium dominance would not develop with the Project, either during or following dredging. Given the remediation work is taking place over a relatively short period of time (i.e., scale of months for each management unit), and with backfilling of cleaner materials on top of the post-dredge surface, there is not enough time for the transformation of trivalent to hexavalent chromium. Amanatidou (2023) describe the environmental conditions that cause transformation of chromium in natural environmental media, and conclude that:
Amanatidou E. 2023. Speciation, Chemistry, Geogenic Formation and Dispersion of Chromium in Groundwater. In: Kumar N, Walther C, Gupta DK (eds), Chromium in Plants and Environment. Environmental Science and Engineering. Springer, Cham.
Metals in the harbour that are elevated include chromium, mercury, arsenic, and copper. These metals mainly came from historical industry along the harbour front, by either being directly deposited or washed into the harbour with surface water or ground water. For example, chromium in the harbour comes from the chrome tanning process used at the Davis Tannery that was immediately next to the harbour for much of the 20th century. Metals in the harbour can pose both ecological and human health risks depending on the type and where they occur.
PAHs occur naturally in coal, crude oil, and gasoline, and are produced from burning. PAHs are a common contaminant in urban waterways, and come from numerous sources, including storm sewer outlets from road run-off, automobile exhaust, furnace/stack emissions, or spills from fuel depots/marinas. Historical coal stockpiles, oiling docks, and rail yards in Kingston Inner Harbour, along with the former coal gasification plant in downtown Kingston, are thought to be the most significant sources of PAHs to the harbour. These chemicals break down naturally (i.e., biodegrade) in the environment, but this process can take a very long time depending on the type and amount of PAHs present. PAHs in the harbour can pose risks to both ecological and human health.
PCBs are human-made chemicals that were used widely in electrical equipment like capacitors and transformers, and previously found in hydraulic fluids, heat transfer fluids, lubricants, and plasticizers. PCBs were mostly washed into the harbour with surface water and groundwater running through the former Belle Landfill. Because they can cause negative health effects at low levels in people and wildlife, the import, manufacturing, and sales of PCBs were made illegal in Canada in 1977. In Kingston Inner Harbour, PCBs were most likely released into the environment through leaks from a former landfill, scrap yard, and demolition yard. Once in the environment, PCBs stick to soils and sediments and can be transported long distances from their original source. They also bind strongly with fatty animal tissues and magnify in the food chain, meaning they are passed into and accumulate in larger animals when they eat smaller animals. These chemicals break down (i.e., biodegrade) very slowly and can last a very long time in the environment. PCBs in the harbour can pose risks to both ecological and human health.
No, there are no ongoing sources of contamination from historical sites. Understanding and addressing the potential for recontamination is essential for contaminated sites projects. Most of the contamination in the harbour resulted from historical activities in surrounding areas. Left-over contamination in most of those surrounding areas is being managed, or planned for management, which will help prevent future contamination of the harbour. For example, a groundwater system was installed at Emma Martin Park to prevent metals from moving into the harbour, and a leachate management system was installed at the former Belle Park landfill to collect water moving through the landfill and stop PCBs from leaving the landfill site.
The conceptual sediment management plan recognizes that Kingston Inner Harbour is a working harbour, so it could continue to receive new inputs from active uses (e.g., storm water, boat traffic, fuel spills). For that reason, the goal of the plan is to manage the contamination to lower, more acceptable risk levels, not to remediate to pristine conditions. Ongoing sources are not expected to worsen conditions beyond the safe level, and the current environmental regulations and best practices will reduce the likelihood of new contamination. After dredging and sediment capping is complete, the harbour will be monitored long-term to provide confidence that the remaining concentrations of chemicals will stay the same or decrease over time. The federal government is working with the City of Kingston to monitor street runoff and other inputs from storm sewers, and to provide confidence that ongoing flows do not threaten the health of the harbour.
Overall, water quality in Kingston Inner Harbour (KIH) is considered good. This is because a large proportion of the chemicals found in KIH are tightly bound to the sediments and do not easily dissolve in surface water. Even though there are some chemicals in KIH water that are higher than in upstream areas, they aren't at levels that need any extra actions, other than what has already been planned for this project.
To further understand the impact of different weather conditions (such as rainfall) on KIH water quality, and check for emerging contaminants and source controls (controlling pollutants at their source), we recently collected additional water quality and sediment samples from storm sewer outlets, including the one flowing into Orchard Street Marsh (Kingscourt stormwater discharge). We have analyzed results for legacy contaminants (the former industrial sources), nutrients (agricultural inputs), and emerging contaminants (chemicals such as fire retardants associated with urban activity not associated with former industry). These results show evidence of source control, confirm stormwater quality for discharges to KIH, and provide information used for design of the Project. Water quality monitoring information will be shared with the City of Kingston for consideration in their regional program of municipal source controls and stormwater management.
The term “risk” means there is a chance or probability of harm to people and/or the environment if they have been exposed to certain chemicals. It is called a risk because harm is possible, but it may not always happen, or may happen only to a small group of individuals. The risk level depends on the amount of exposure, pre-existing health, and other factors. An environmental risk assessment is a scientific process used to describe and estimate the chance of negative health effects (i.e., potential risks). Risk assessments tend to be conservative and err on the side of caution, as under-estimating the level of risk could have harmful consequences.
Risk refers to the chance or probability of an unwanted effect, so we are looking at the chance or probability of harm to people and/or the environment if they have been exposed to chemicals in the sediment. For humans, the main risks in the harbour are from exposure to PAHs and PCBs (metals are less of a concern, except possibly for methylmercury). High exposure to PAHs and PCBs may cause negative health effects in people. The main concern for exposure to PAHs is an increased risk of cancers, but for PCBs there are also concerns about effects to the immune system, reproductive system, the brain, glands, or organs. Exposure to metals, PAHs, and PCBs are all potential issues for wildlife (birds, mammals, reptiles, amphibians, fish, and benthic invertebrates). Effects of exposure to these chemicals can include poor development of young animals, deformities in adult animals, and potentially death.
Nearly all human activities have some risk. The study of health risk assessment is intended to measure those risks, so that regulators and the public can understand them better, and where necessary, can reduce those risks to an acceptable level. In deciding what levels of risk are acceptable, risk assessors first evaluate whether the risks are voluntary. Most people are willing to take on risk to their health when they understand the nature of the risks involved and when they can exercise some control over the degree to which they take on those risks. For example, the act of driving a car has a moderate risk, yet many people accept the dangers of driving because of the benefits of driving, their understanding of those risks, and partial control over those risks. Risks of chemicals/contaminants in the environment are treated differently because they are mostly non-voluntary and invisible.
An environmental risk assessment is a scientific process used to describe and estimate the chance of negative health effects (i.e., potential risks) to humans and wildlife (e.g., birds, mammals, reptiles, amphibians, fish, and benthic invertebrates). These chemical risks can result from deliberately or accidently touching, breathing in, eating, or drinking contaminants at a site. For a risk to exist, three things must be true: 1. the amount of the chemical in the environment is high enough to potentially harm organisms 2. organisms that can eat or be exposed to the chemical must be present at the site; and, 3. there must be a way for the organism to have contact with the chemicals. When moderate or high risks (see definitions of risk categories below) are observed in an environmental risk assessment, clean-up and/or a risk management plan is required to address the risks so that people, and/or wildlife are protected.
Risk assessors categorize risks based on the level of threat to health. For human health, we look at the chance of a serious negative health outcome (e.g., cancer) or the degree to which a long-term chemical exposure exceeds a level considered by scientists to be safe. In ecological risk assessment, a similar approach is used, and focuses on health risks to communities of animals such as wildlife and their food. To help summarize risks, we often use terms such as “negligible risk”, “low risk”, “moderate risk”, and “high risk”. These categories summarize complex and detailed information into simple categories. Examples are provided below.
Negligible risk (safe for unlimited use): A risk that is so low that it can easily and confidently be concluded to be safe. For human health, this means that people can have unrestricted exposure to the site without increasing their risk in a meaningful way. For ecological health, negligible risk means animals are protected in terms of their survival or ability of grow, develop, or reproduce normally. As an example, negligible risk occurs when site contamination falls within the normal background levels for a chemical substance in water, sediment, and fish tissue.
Low risk (generally safe but with possible restrictions): A risk that is acceptable to nearly all users of the site. Exposure may exceed background levels or screening guidelines, but without causing any major threat to health. Under a low-risk condition, it is possible that a small number of individuals with very high exposure and high sensitivity could be affected. For this reason, controls may be required to keep risks low (e.g., a fish consumption advisory). For ecological risk assessment, low risk means that a small number of individuals of common species might have minor responses, but the populations and communities remain healthy, diverse, and productive.
Moderate risk (may be unsafe): A risk that is considered unacceptable in the long-term, based on the potential for damage to health. A moderate risk does not represent an emergency, or even definitive evidence of harm to health, but instead requires a careful plan to reduce exposure. For human health, moderate risk occurs when people consume more than a daily recommended intake of a substance. For ecological health, moderate risk means that adverse effects are expected to individuals of sensitive species, which may or may not result in a less healthy population.
High risk (clearly unsafe): A risk that is unacceptable, has clear evidence of negative health effects, and that requires fast action to reduce exposure. An example of a high risk that can occur in everyday life is contamination of meat or produce by bacteria such as Escherichia coli (E. coli). Under certain conditions, food products can be contaminated to a degree that requires a response from the Canadian Food Inspection Agency to protect public health. The same principle applies to contamination by chemicals, such that high risks from spills or concentrated areas of chemicals can require a fast response. For ecological health, high risk conditions can occur from an environmental spill, requiring prompt action to prevent widespread environmental damage.
The Project aims to reduce chemical risks to a level that protects both people and the environment, consistent with the standards used by the federal government for other contaminated sediment sites in urban harbours. To do this, some sediment will need physical intervention but it is not necessary to lower all chemical levels and areas to the strictest sediment guidelines. The goal is to focus cleanup where chemical risks are highest while ensuring the protection of wildlife habitats, archaeological, infrastructure, and recreational values. Cleanup will reduce chemical risks in the areas where physical intervention occurs and will also speed up the recovery of other areas over the long-term as sediments continue to move throughout the harbour. This balanced approach will also take into account values of Indigenous Groups, stakeholders, and the public.
There is no health emergency or need for urgent action. Risks to human health from harbor sediments are considered moderate, but not severe, and would continue for decades if not managed. Water quality remains acceptable and does not require management separate from the sediment management plan. If people do not eat a lot of local fish and do not have regular contact with the contaminated sediments, the risk is low. A fish consumption advisory is in place (https://www.ontario.ca/page/eating-ontario-fish). Most recreational activities in and around the harbour, like boating, kayaking, rowing, and hiking, are safe if skin contact with sediment is minimized or avoided. People should avoid touching the sediments (including contact through swimming). If sediment does contact your skin, simply rinse it off and wash your hands before eating.
For several decades, it has been known that Kingston Inner Harbour (KIH) had high levels of contamination due to historical industries and land uses. This process of assessing the environment in the KIH began over 20 years ago, to identify what locations and levels of contamination are present, where contamination is coming from, what the associated risks may be and, if necessary, what strategies are needed to manage unacceptable risks.
We know that the main upland sources of sediment contamination have stopped and/or have been controlled. These studies also show that the recovery of the sediment quality in the harbour has been slow or not happening in most areas, and some contaminated sediment continues to spread out into other sections of the harbour. Now that the environmental risks have been identified, under the federal process we need to take action to address the areas that are too contaminated to be safely left in place.
Letting natural processes continue (called monitored natural recovery) was considered throughout the Project and is the recommended approach for the majority of the Kingston Inner Harbour (KIH) where contamination levels are lower. If the results of sediment sampling at the site had shown strong evidence that natural recovery was happening over time, we would have proposed managing even more of the KIH sediments using monitored natural recovery. Unfortunately, in some areas, evidence from field sampling shows that natural recovery alone is not enough for sediment quality to recover over multiple decades. This has been confirmed by sediment samples from 2021-2024 showing that in the last 10-15 years, concentrations of chemicals have shown little change; there are still elevated levels of several chemicals, and associated health risks in near-surface sediment where animals live and feed. The risks vary in magnitude and type over different parts of the harbour, but there are multiple contaminants and sensitive groups affected under current conditions. This means that action is needed in these areas of higher contamination where natural recovery is not sufficient to control risks.
If these higher chemical levels were consistently buried deeper, and covered by a stable clean layer of material, this may also have allowed for more monitored natural recovery. Unfortunately, significant contamination remains; some of it is at the surface and at shallow depths. Natural processes in the harbour also cause sediments to move and mix from various activities including those by animals as well as wind, wave and ice action. These activities maintain high surface contamination despite upland sources being stopped or controlled for many decades. Recent field testing also confirms that sediments continue to move and mix around the harbour.
Because chemicals are present above safe levels and are not lowering over time, active sediment management is necessary. Taking targeted actions will reduce the chemical risks in key areas, improve conditions quickly, and will stop or slow the spread of contaminated sediment further out in the KIH. The balance between intervention and the disruption to the natural environment is being carefully considered in both the detailed project design and the environmental impact assessment.
No, you should not be worried if you have been swimming/recreating in the harbor. Most recreational activities in and around the harbour, like swimming, boating, kayaking, rowing, and hiking, are considered safe since contact with the sediment is minimized or avoided during these activities. People should avoid touching the sediments and eating anything that may have touched the sediments. If sediment does contact your skin while you are using the harbour, simply rinse it off and wash your hands before eating.
Seeing wildlife in the harbor does not mean that they are not being negatively affected by contamination. Although the presence of turtles and other wildlife in the harbour is a good sign that the sediment is not causing severe negative effects to wildlife in the short-term, it may be causing underlying health conditions or community-level impacts that may not be easily seen or observed in all of the population. Effects of wildlife exposure to metals, PAHs and PCBs can include poor development, decreased reproduction rates, deformities or tumors, and mortality. For example, physical abnormalities, such as skin tumors, have been seen in some brown bullhead fish in the harbour that are likely caused by contact with the sediment.
Yes, most recreational activities in and around the harbour, like swimming, boating, kayaking, rowing, and hiking, are safe if skin contact with sediment is minimized or avoided. People should avoid touching the sediments and eating anything that may have touched the sediments. If sediment does contact your skin, simply rinse it off with and wash your hands before eating. Consumption of fish from the inner harbour is not recommended, and anglers are advised to consult the Guide to Eating Ontario Sport Fish (www.ontario.ca/environment-and-energy/eating-ontario-fish) for identification of areas in the Kingston region where consumption risks for fish flesh are lower.
Contaminated sediment will be safely removed by using standard and acceptable environmental controls and practices. Dredging is a safe and common practice for removing contaminated sediment and has been effectively done in harbours throughout North America. Dredging can be done by using a closed bucket to prevent losing sediment as it is brought up, or through suction dredging using a vacuum-like pump to remove the sediment. As part of the detailed design process, technologies best suited to each area to minimize negative impacts will be selected, and an environmental management plan will be prepared. The environmental management plan will describe how project activities can be conducted safely and what environmental controls must be in place during the project to prevent any accidental environmental effects, such as water or sediment quality impacts, physical danger to wildlife, or damage to archaeological values.
The environmental management plan (to be prepared as part of detailed design) will outline measures to prevent resuspended sediments (i.e., sediments that move from the bottom of the harbour into the water column) from spreading to other areas of the harbour or beyond. Typically, this includes the use of sediment curtains (i.e., physical barriers placed around the areas that are being dredged) at all times when dredging is occurring. The environmental management plan will also require that water quality meet background ranges and/or approved water quality guidelines for the protection of aquatic life outside of the areas actively being dredged. Environmental monitoring and sampling for water quality will be done during dredging to verify that the above conditions are met. These measures, which combine engineering approaches with best management practices, are commonly applied in sediment excavation and capping projects and have been shown to be effective at containing resuspended sediments.
Yes, many similar projects have been done in the past. You can find information on those projects using the links below. Dredging, which is the method we will be using in the harbour, is a standard and reliable technique for removing contaminated sediment. It has been used to clean-up hundreds of aquatic contaminated sites in North America. Examples of recently completed successful clean-ups of aquatic contaminated sites using dredging include:
The Kingston Inner Harbour Sediment Management Project does not include dredging in the Orchard Street Marsh, which is recognized as a highly sensitive area and part of the Provincially Significant Greater Cataraqui Marsh wetland. Instead, the proposed plan for Orchard Street Marsh entails low intervention marsh rehabilitation (i.e., no dredging or capping options) and will be limited to Enhanced Natural Recovery (ENR). An example of this ENR method is the placement of very fine layers of binding materials (like activated carbon) that will cause the chemicals in wetland sediment to be less available to aquatic organisms – thus reducing ecological risks. Since this layer is very thin and can be applied from a distance, its is expected to have very little impact on existing vegetation and ecological communities.
Beyond the federal water lots, there are additional areas of contaminated marsh sediment that are not part of this Project. There are opportunities for long-term collaboration with other parties that own or manage these adjacent portions of the provincially significant wetlands. The activities for the federal water lots are being designed to allow for compatibility with environmental management of those other areas so that risks might be further reduced over the longer term.
The depth of contaminated sediments requiring dredging varies across the harbour, because the soft, silty sediments that contain the contamination varies in thickness. The thickness in each management unit has been evaluated using tools such as ground penetrating radar and additional subsurface coring. Over much of the harbour, the thickness of contaminated soft sediment is less than 1 metre, but there are areas where deeper excavations are needed. Below the soft sediment lies a native lake clay layer that is not contaminated because that material was deposited long before the pollution happened. Samples have confirmed that this underlying clay layer is clean and provides an excellent marker horizon to indicate the limit of dredging depth needed. It is currently estimated that approximately 69,500 m3 of sediment will need to be dredged from the KIH (Stage 1 - 17,500 m3 and Stage 2 - 52,000 m3), but this volume continues to be refined as engineering design work progresses.
The project team is still deciding where the removed contaminated sentiment will go and how it will be transported there. These details will be developed further during the detailed design phase. Generally, excess water from the dredged sediment will first be removed (i.e., dewatered) so that it is more stable to transport and then will likely be transported by haul trucks to approved and regulated landfills for disposal. The dredged sediment may also be stabilized and solidified to bind the contaminants in a solid form, and make the material more easily transported by trucks and/or barges. Any excess water generated during this process will be tested and treated if necessary. Disposal facilities, once selected, will hold a valid permit, license, certificate, approval, or any other form of authorization issued by a Facility Regulator (i.e., federal or provincial government) for the handling and disposal of contaminated or Hazardous Waste Quality Materials (if required). As part of the detailed design and impact assessment process, an environmental management plan will be prepared to make sure that the material is appropriately transported and disposed of.
“Ex situ” means off site; any sediments dredged from Kingston Inner Harbour (KIH) would be permanently removed and safely disposed of at an approved, permitted landfill outside the Project area.
“Sediment disposal” is the main method of sediment removals for the Project and entails transport by truck of dewatered sediments from KIH directly to a permitted landfill; no sediment treatment is required for these materials provided that the dredged sediments, called dredgeate, meets the landfill operator’s criteria for chemical and physical parameters. The specific location (destination) of the landfill(s) has not been prescribed, but any option must satisfy provincial requirements for safe landfill disposal. The requirement for any special treatment or disposal methods will be evaluated by taking additional chemical measurements and/or conducting leachability tests prior to off-site transport.
“Sediment treatment” applies a process to destroy, or remove exceptionally high levels of contaminants from dredged sediments so that they can be disposed of using conventional landfills. Most of the sediments in KIH will not need this type of treatment because they are not expected to have contaminant concentrations that would classify them as “hazardous waste”. Sediment treatment would only be needed if pockets of hazardous wastes are identified during the project. Treatment, if needed, would only be conducted at a special facility, such that no dust, vapours, or poisons that pose potential health risks would be generated. There is a possibility that some excavated coal-tar contaminated sediments near Anglin Bay may require treatment, but these would be limited to small volumes of material (called free product) derived from the legacy coal gasification source(s).
A Detailed Impact Assessment (DIA) will be completed, consistent with Parks Canada’s Impact Assessment Directive and the requirements of the Canadian Impact Assessment Act (https://laws.justice.gc.ca/eng/acts/I-2.75/index.html), to determine whether any aspects of the recommended plan would be likely to cause significant adverse environmental effects. The DIA will consider potential changes to the environment that are likely to be caused by the Project; technically and economically feasible mitigation measures that would prevent or minimize adverse effects; and, the impact that the project may have on the rights of Indigenous Peoples. The DIA will include a summary of formal consultation with Indigenous communities and a public comment period. The Detailed Impact Assessment may result in further design changes if it is found that there is the potential for significant negative effects on the environment from the current proposed project. The need for removing and/or containing chemicals will be balanced with respect for the environment, especially in sensitive areas. It is recognized that some of the areas contain features or habitats of greater sensitivity, such as shipwrecks of archaeological value, wetland and marsh areas, or shoreline areas used by turtles, birds, and other wildlife for nesting, feeding, and basking. The conceptual sediment management plan has been updated to recognize these sensitive areas and proposes different, and less intrusive, methods for sediment management based on the current information. However, more detailed biological and ecological studies are being done as part of the DIA process to finalize the sediment management methods.
In support of the DIA process, a Conceptual Constraints and Impact Considerations (CCIC) document was completed (SNC-Lavalin 2023) to provide preliminary high-level considerations of potential impacts from the project based on information gathered to date.
The need for removing chemicals will be balanced with respect for the environment, especially areas of sensitive or valued habitats. It is recognized that some of the shoreline areas contain habitats of greater sensitivity, such as wetland and marsh areas, or shoreline areas used by turtles, birds, and other wildlife for nesting, feeding, and basking. The conceptual sediment management plan recognizes these sensitive areas and proposes different, less intrusive, methods for sediment management, including nature-based shoreline solutions. In some areas, dredging will be excluded entirely to avoid unacceptable alteration of habitat. There will also be habitat gains through this project in the restoration of shorelines or other low value habitats. The methods being proposed to protect sensitive species, habitats and valued features are provided in the updated conceptual sediment management plan and will be evaluated in detail during the impact assessment.
The federal government has been conducting fish habitat surveys to document sensitive habitat features. In addition, the team is using a Habitat Ecosystem Assessment Tool (HEAT) to scientifically assess and predict the net change in habitat productivity. The HEAT model combines information on fish habitat inventory with habitat requirements specific to critical life stages; it was developed to evaluate proposed development project effects on fish habitat and has primarily been applied in the Great Lakes region. The Project will follow a “no net loss” guiding principle (to achieve no net loss of the productive capacity of aquatic habitats) for any of those spawning species, and the assessment will be included in the Detailed Impact Assessment for Kingston Inner Harbour, which contains sections specific to fish and fish habitat.
The Project team is engaging with Fisheries and Oceans Canada, the Ministry of Natural Resources and other environmental agencies to ensure the necessary permits, approvals, and guidance for the Project are met.
Removal of the contaminated sediment using the proposed methods is the best way to permanently reduce health risks. The need for removing chemicals will be balanced with respect for the environment, especially areas of sensitive or valued habitats. For example, the sediment will be removed when fish are not spawning and when turtles are not moving across the work area or overwintering. An initial assessment of sensitive habitats and ways to avoid harm to these habitats is included in the conceptual sediment management plan, and will be evaluated in detail during the impact assessment and detailed design.
The current sediment management plan includes the use of dredging exclusion zones (areas where sediment will not be removed) along the shoreline to preserve the integrity of shorelines, sensitive habitats, and archaeological features in some areas. There may also be habitat improvements because of the planned nature-based shoreline rehabilitation along the inner harbour. This will include shoreline plantings that will preserve ecological habitat (including turtle habitat) and prevent/reduce erosion.
We will do as much as possible to reduce the negative effects of this project to local businesses. As part of the project planning and stakeholder engagement process, businesses operating in the harbour will be contacted to ensure the project team has a good understanding of their operational needs, so that potential impacts to operations associated with the project can be identified and managed.
This information will be incorporated into detailed design and project implementation plans. Given the project is still in the planning stages, exact schedule and impact to business operations are still unknown; however, we will work with business operating in the harbour to minimize and/or eliminate impacts to their operations.
No, drinking water in downstream areas will not be an impacted by this project. Sediment management projects such as these are very safe, and the technologies being proposed (such as dredging) are common practice for removing contaminated sediment from harbours. The project will use appropriate environmental controls such as sediment curtains, and environmental monitoring, including taking measurements for water quality and sediment quality outside of the dredging areas, will also be conducted to confirm that chemicals harmful to people, or wildlife are not spread into other areas of the harbour or into Lake Ontario where most of Kingston’s drinking water comes from.
The project team is still deciding how often and for how long the harbour will be monitored after sediment management. Details of the monitoring program will be developed as planning progresses. Federal monitoring programs for this type of work typically involves intensive daily monitoring during project implementation to make sure that it is following the project’s prescribed environmental protection plan, followed by short-term yearly monitoring (~1–5 years) and a long-term monitoring component (~10+ years) that happens less often (e.g., every few years) to confirm that habitat restoration has been successful and that sediment management goals continue to be met.
As part of the project planning and stakeholder engagement process, businesses operating in the harbour will be contacted to ensure the project team has a good understanding of their operational needs, so that potential impacts to operations associated with the project can be identified and managed. This information will be incorporated into detailed design and project implementation plans. Given that the project is still in the planning stages, exact schedule and impact to business operations are still unknown; however, we will work with business operating in the harbour to minimize and/or eliminate impacts to their operations.
No, dredging will not be conducted year-round. For projects of this type, dredging must respect timing windows to protect sensitive biological stages of fish, reptiles, and other animals that may be present. Dredging is based on a tentative five-month window – May to September, inclusive. These windows may be refined based on individual water lot habitat features as part of the Detailed Impact Assessment (DIA) and in discussion with other regulators like Fisheries and Oceans Canada and Environment and Climate Change Canada. These windows will be tailored depending on the sensitivity of the management unit.
No, dredging will not threaten the local drinking water supply. Several environmental protection measures will be implemented to protect water quality during the project. Heavy-duty turbidity curtains (or similar isolation measures) will be used to isolate the work areas and protect against sediment releases; these turbidity curtains are floating barriers that are weighted at the bottom to contain sediment that is stirred up by in-water activities. The project’s environmental management plan will provide specifications for controlling sediment-laden water, including performance measures for dredging within the work zone, environmental monitoring outside the work zone, and water quality standards prior to discharge of water to Lake Ontario through the LaSalle Causeway.
The water quality during the Project will be best managed by controlling turbidity. Turbidity curtain performance is well understood in Ontario conditions and will include lessons learned from the Waaban Crossing Project just north of Kingston Inner Harbour (KIH). As part of the federal Detailed Impact Assessment for KIH and the ongoing detailed design process we are setting site-specific water quality criteria. Real-time water quality monitoring will be used to ensure that these thresholds are not exceeded outside of work areas during project activities.
We are also taking extra steps to verify, through water quality modelling, that there would be no risk to the City's water supply in the unlikely event that there was a failure of sediment containment measures during the work. This modelling, in conjunction with the implementation of environmental controls during dredging, and downstream monitoring of water quality will ensure the protection of drinking water. During project implementation, adaptive management controls will be applied, including strict controls for contractors to shut down work if water quality thresholds are exceeded immediately outside the isolated work areas.
Previous industrial activities in areas surrounding Kingston Inner Harbour resulted in the contamination of sediments (sand/silt/clay lining the lake bottom) in Transport Canada, Parks Canada, and City of Kingston water lots. The chemicals of concern include metals, polycyclic aromatic hydrocarbons (PAHs) and polychlorinated biphenyls (PCBs). The chemicals are mostly from historical land uses, including a former rail yard, landfill, coal gasification plant, tannery, lead smelter, shipyards, fuel and oil docks, scrap/demolition yards, and other industrial activities. Scientific studies have found that the contamination in the Kingston Inner Harbour may pose risks to the health of humans, fish, birds, mammals, and other aquatic life. Despite several decades of being left to recover, some areas have not recovered enough to be safe, and would not be safe for a very long time without help from the sediment management project.
Sediment investigations and risk assessments were completed by Golder Associates (now WSP) on behalf of Transport Canada and Parks Canada following standard federal and provincial guidance. The guidance included the Canada-Ontario Decision-Making Framework for Assessment of Great Lakes Contaminated Sediment (ttps://publications.gc.ca/collections/collection_2010/ec/En164-14-2007-eng.pdf) and the Framework for Addressing and Managing Aquatic Contaminated Sites under the Federal Contaminated Sites Action Plan (https://www.dfo-mpo.gc.ca/pnw-ppe/fcsap-pascf/docs/1-eng.htm).
Federal departments (including Public Services and Procurement Canada, Health Canada, Fisheries and Oceans Canada, and Environment and Climate Change Canada) reviewed the investigations and provided feedback to Parks Canada and Transport Canada during these studies. Where warranted, changes were made to the technical reports in response to the suggestions made by the Federal Expert Support Departments. Independent scientific studies were also done by the Environmental Sciences Group of the Royal Military College over the last fifteen years. The results and recommendations of their studies were reviewed in a similar way and were consistent with those completed by Transport Canada and Parks Canada. Since the same conclusions were reached by different studies, this provides confidence that the outcomes of the investigation are scientifically sound.
The strategy was designed to balance the least amount of environmental disturbance with the greatest degree of contaminant risk removed. With this in mind, the strategy, outlined in the conceptual sediment management plan, includes leaving sediments alone for most of the harbour, because the risks in most areas are low. Physical management (including areas of dredging, capping or shoreline engineering) will only be used in areas where risks are greatest to people, fish, or wildlife. Although sometimes nature can heal itself by either breaking down contaminants or slowing burying them with cleaner deposits, these processes are not always effective and can take a very long time. For example, the recent sediment quality monitoring in Fall 2021 confirmed that there was little improvement in the sediment contamination over the last 15 years. In Kingston Inner Harbour, the burial of contaminated sediment is very slow, as sediments are frequently stirred up by waves, ice, fish, and human activities. So, waiting for the harbour to recover naturally would take a very long time, and people, fish, and wildlife could experience more negative health effects because of this waiting period.
Some areas in the harbour are also an ongoing source of contamination to the cleaner areas because the sediments are redistributed throughout the harbour, as documented by the sediment transport investigations.
Yes, the strategy follows scientific investigation methods, combined with a standardized approach for assessing and managing contaminated sediments across Canada. The process for the sediment management plan was based on guidance developed by both the Canadian and Provincial governments (Canada-Ontario Decision-Making Framework for Assessment of Great Lakes Contaminated Sediment and Framework for Addressing and Managing Aquatic Contaminated Sites under the Federal Contaminated Sites Action Plan). This guidance provides a science-based, ecosystem-wide approach to sediment assessment and considers potential effects on aquatic life, as well as potential for contamination to accumulate in the food chain.
The Framework used was meant to standardize the decision-making process while also being flexible enough to account for site-specific considerations. The Framework provide a tiered scientific process of investigation and, includes some guiding principles that have been applied to the strategy, including: (1) that it will be applied within the context of common sense (not applied inflexibly); (2) that potential sources of ongoing contamination are addressed before undertaking clean-up; and (3) that the impacts of the plan do not cause more environmental harm than good.
No, the plan is not yet final. It is currently at the concept stage, and will be refined based on feedback from Indigenous communities, local stakeholders, and the public, as well as results from further biological, chemical and archeological studies of the harbour. Feedback about the project to date was used to make changes to the conceptual design before the detailed design. More engagement will happen at milestone stages of the project, and are being integrated into the Detailed Impact Assessment that is currently in progress.
The sediment in some areas needs to be removed to keep people and wildlife (fish, aquatic life, mammals, birds, turtles) safe from contamination. The conceptual sediment management plan suggests that we leave sediments alone for most of the inner harbour, because the risks to people and wildlife in most areas are low. Removal of the sediment was only selected in areas where the risks to people and wildlife were unacceptably high. The conceptual sediment management plan also balances the desire to limit the amount of environmental disturbance, and limit the costs and disruptions associated with the clean-up, while reducing the risk to a safe level. Some sediment needs to be removed (i.e., dredged) because it contains high concentrations of chemicals that can cause contamination and are harmful to living organisms. These chemicals can stay in the environment for a long time and treating sediment in place is very difficult. Fish may eat items that have been exposed to the sediment contamination, and birds or people could then eat the fish. Also, the contaminated sediment might touch the skin of people that wade or swim in the harbour, or people could swallow it by accident. By carefully removing areas of contaminated sediments, while using environmental controls to prevent spreading of these contaminants throughout the harbour, we can reduce the amount of contamination in the harbour and the risks to people, mammals, birds, turtles, fish, and their food.
Although sometimes nature can heal itself by either breaking down contaminants or slowly burying them with cleaner deposits, these processes may not be fully effective and/or can take a very long time in areas where contaminant inputs have overwhelmed nature’s capacity to heal. In Kingston Inner Harbour (KIH), the answer depends on the section of the harbour, as the contamination differs among areas of the harbour with respect to both overall magnitude of contamination and combinations of chemicals present. In a significant portion of the harbour, the level of contamination is low enough that the slow ongoing processes of degradation and burial are sufficient. However, in other areas the degree of contamination has exceeded nature’s capacity to recover naturally; the continued presence of moderate to high levels of some chemicals, despite the legacy source being discontinued, shows that natural river processes on their own, although important, have not yielded a reduced acceptable risk over a reasonable time frame. In KIH, the burial of contaminated sediment is very slow, as sediments are frequently stirred up by waves, ice, fish, and human activities. These areas are also an ongoing source of contamination to the cleaner areas because the sediments are redistributed throughout the harbour, as documented by the sediment transport investigations.
We can't leave the harbor the way it is because it is currently not safe for people and wildlife. The goal of the sediment management project is to make the harbour safe for recreational activities for people (e.g., wading, swimming, and fishing), and for wildlife to live in and around the harbour. In some areas of the harbour, there are visible negative effects (e.g., fish deformities, aquatic community disturbance), while other effects are not easily visible (e.g., long-term human health effects).
Letting natural processes continue (called monitored natural recovery) was considered throughout the Project and is the recommended approach for the majority of the Kingston Inner Harbour (KIH) where contamination levels are lower. If the results of sediment sampling at the site had shown strong evidence that natural recovery was happening over time, we would have proposed managing even more of the KIH sediments using monitored natural recovery. Unfortunately, in some areas, evidence from field sampling shows that natural recovery alone is not enough for sediment quality to recover over multiple decades. This has been confirmed by sediment samples from 2021-2024 showing that in the last 10-15 years, concentrations of chemicals have shown little change; there are still elevated levels of several chemicals, and associated health risks in near-surface sediment where animals live and feed. The risks vary in magnitude and type over different parts of the harbour, but there are multiple contaminants and sensitive groups affected under current conditions. This means that action is needed in these areas of higher contamination where natural recovery is not sufficient to control risks.
If these higher chemical levels were consistently buried deeper, and covered by a stable clean layer of material, this may also have allowed for more monitored natural recovery. Unfortunately, significant contamination remains; some of it is at the surface and at shallow depths. Natural processes in the harbour also cause sediments to move and mix from various activities including those by animals as well as wind, wave and ice action. These activities maintain high surface contamination despite upland sources being stopped or controlled for many decades. Recent field testing also confirms that sediments continue to move and mix around the harbour.
Because chemicals are present above safe levels and are not lowering over time, active sediment management is necessary. Taking targeted actions will reduce the chemical risks in key areas, improve conditions quickly, and will stop or slow the spread of contaminated sediment further out in the KIH. The balance between intervention and the disruption to the natural environment is being carefully considered in both the detailed project design and the environmental impact assessment.
It is not possible or necessary to remove all of the contaminants from the sediment, so it is not necessary to completely remediate the harbour. Low levels of chemicals are safe and common in active harbours and urban environments. The goal is to remove the sediments with the highest amounts of chemicals to reduce the risks to an acceptable level, where people and wildlife are unlikely to experience negative health effects. The level deemed safe is based on science and the protection goals for the harbour. Reaching safe levels will be monitored during and after the project to make sure that the methods used to clean up the harbour’s sediment work as they are supposed to.
Remediation typically involves removing contaminants from a site through on-site treatment or off-site disposal. Risk management typically involves managing contaminants in place, using covers and/or measures to block the exposure pathways that could cause potential risk (e.g., through directly contacting the contaminated sediment). Often, risk management does not require any physical changes to the environment, but it does require monitoring how the environment is recovering over time. Both remediation and risk management strategies are designed to reduce risks, and both strategies can be protective of human and ecological health. Various factors (e.g., engineering feasibility, financial responsibility, legal considerations) must be considered when choosing which remediation and/or risk management option(s) to use. Remediation and risk management measures can be used either alone or in combination to successfully manage risks in an environmentally and financially responsible manner.
Shoreline works are being proposed to reduce the levels of these nearshore contaminants and limit accidental contact with the sediment. Nature-based shoreline rehabilitation is planned along the inner harbour. This includes shoreline plantings typical to uplands, wetlands, and submerged aquatic vegetation. This will improve the quality of ecological habitat (including turtle habitat) and prevent/reduce risk of erosion, while limiting the potential for human access to the water and addressing nearshore contamination (where applicable). The plan also includes the use of dredging exclusion zones between the dredging footprint and shoreline, where sediment will not be removed, to preserve the integrity of shorelines, sensitive habitats, and archaeological features in some areas.
To reduce potential human health exposure, any consumption advisories for fish should be followed.
There may also be some potential risks to human health from the contamination that will remain along the shoreline given that there will be no remedial dredging within a buffer zone to protect sensitive ecological habitats. However, the sediment management plan includes planting natural vegetation along the shoreline in these areas that will prevent humans from accessing the shoreline for swimming or wading.
The project team is working on finalizing timelines, and they will be confirmed during the design process. Initial consultation and engagement with Indigenous nations, communities, stakeholders, and interest groups was completed in 2021 to improve the initial conceptual sediment management plan prepared in 2021. Consultation and engagement is still ongoing to get feedback on the revised conceptual sediment management plan that was completed in 2023. Additional engagement will continue as the Detailed Impact Assessment and detailed design process are completed. It is estimated that the Detailed Impact Assessment and detailed design for the Project will end in 2025, and physical works could begin in 2027; however, this could change as planning progresses. Physical works are anticipated to take 3 years to complete. Once the physical works are complete, long-term monitoring of the site will take place. Click here to visit the “Project Timeline” section for more details.
Yes, shoreline work will be as protective of habitats next to the harbor and recreational and aesthetic values. The goal of the project is to reduce the potential for exposure of humans and wildlife to contaminants near the shore, while also preventing shoreline work from negatively impacting wildlife habitat (e.g., turtle access to laying areas), and preventing erosion. To achieve this, sediment management will focus on nature-based shorelines. This will include:
Specific design of shoreline features will be completed during the detailed design phase and will include consideration of feedback received during additional Indigenous and stakeholder engagement, as well as engineering factors, hydrological processes, and beneficial habitat features.
It is understood that the City of Kingston has shoreline improvements planned for the area, and those improvements will be coordinated with the sediment management project.
The sediment management plan is in the conceptual phase, so there is flexibility in design options for shoreline features. Options will be refined through to detailed design based on feedback from Indigenous and stakeholder engagement activities, and results of ongoing studies, including the Detailed Impact Assessment. The ongoing inventory of ecological resources and habitat mapping will be particularly important in refining shoreline plans. Sensitive areas will be accounted for in the design.
We’ve heard strong community preference for naturalized shoreline management strategies. The proposed remediation design includes several features intended to maintain or enhance existing shoreline conditions. Some examples include no-dredge buffer zones, adding natural materials like woody debris, planting native species, and choosing materials that support or improve existing habitats. The amounts and types of nature-based rehabilitation methods are still being evaluated, and the final design will consider factors like: shoreline characteristics (slopes, existing materials), risk of erosion (from storm waves), terrestrial and aquatic habitat characteristics, and archaeological constraints.
Various “softer” shoreline management options can and will be considered to ensure the shoreline incorporates riparian habitat, is functional for wildlife (i.e., maintains turtle access to laying areas), and reduces the potential for exposure to nearshore contaminants. Specific design of shoreline features will be completed during the detailed design phase and will include consideration of feedback received during Indigenous and stakeholder engagement, as well as engineering factors, hydrological processes, and beneficial habitat features. It is understood that the City of Kingston has shoreline improvements planned for the area, and those improvements could be coordinated with the sediment management project. The sediment management plan is in the conceptual phase, and as such, there is flexibility in design options for shoreline features. Options will be refined through to detailed design, based on feedback from Indigenous and stakeholder engagement activities, and results of ongoing studies, including development of the DIA. The ongoing inventory of ecological resources and habitat mapping will be particularly important in refining shoreline plans. Where specific areas of sensitivity are identified, they will be accounted for in the design.
The answer depends on the area of the harbour and the nature of the sediment under the proposed dredged layers, but yes, placement of clean sediment is one of the options being considered for several portions of the harbour. The clean sediment would not be a thick layer, but could be thin layers of either clean sand, siltier natural material (with more organic carbon), or a special layer of material (with activated carbon) designed to reduce chemical uptake and with desirable properties for invertebrates. The sediment management program will also include post-management monitoring. Sediment contamination and the regrowth of aquatic plants and invertebrates in natural habitats will be monitored to confirm that the project objectives have been achieved. If plants and invertebrates are not growing back as expected, additional mitigation measures may be implemented to fast track this restoration. The details of the potential cover design will be outlined in the detailed design phase.
Archaeological assessments, including desktop evaluations, geophysical surveys, and visual inspections, were completed in 2023 to ensure areas and objects of archeological significance (including shipwrecks) are appropriately identified as part of project planning. Geophysical surveys captured high resolution imagery and mapped features located on the bottom of the harbour and assisted in identifying submerged features buried under the sediment. A Remotely Operated Vehicle (ROV) was utilized to collect visual data during investigations. This information was used to assess the context and possible cultural significance of features and to help guide the development of mitigation measures that will ensure impacts to these objects of archeological significance can be avoided. Techniques and instruments used include multi-beam echo sounding (MBES), side-scan sonar, marine magnetometer and sub-bottom profiler.
These resources have been located within the project area and are considered under the archaeological assessment and in the federal Detailed Impact Assessment for Kingston Inner Harbour. They will be protected in two main ways: 1) no-work buffer zones around culturally important areas like Belle Island and no-dredge zones around known features, 2) procedures for unexpected or chance archaeological finds uncovered during project activities, including notifications and stop-work procedures. The design includes a no intervention buffer zone around Belle Island and additional buffer zones around known wrecks. There are also limits applied to the types of physical remediation, such as thickness of cover materials, that can be safely applied near these areas.
Yes, the Project is being designed and implemented to achieve the overall goal, without requiring resolution of all issues related to adjacent land uses. Although cooperation and coordination among non-federal parties that own or manage sediments and shoreline soils in the Kingston Inner Harbour (KIH) is being incorporated into the project planning, it is not necessary to achieve project success.
There are portions of the harbour, particularly along the western shorelines, for which approvals by City of Kingston are required in order to complete the proposed works; these areas include lands and water lots that are either owned by the City or have potential to influence the shoreline design. Engagement is underway with the City to provide a design that achieves the chemical risk reductions required while also respecting City priorities such as shoreline protection, aesthetics, protection of municipal works, and compatibility with the City’s Waterfront Master Plan.
We have not made assumptions in the remediation design that require approval (or lack thereof) of any brownfield redevelopment scenario. Instead, the project is adaptable to changes in the status of the brownfield and can proceed without decisions on the future of the brownfield. The methods proposed for the Orchard Street Marsh (management unit PC-OM), in particular, have been selected with flexibility in mind. Remediation will result in net environmental improvement within the federal water lots, but still leave the door open to additional future improvements if other parties agree on additional shoreline or wetland management. The methods being applied for PC-OM, which includes marsh habitats, are expected to be fully compatible with future decision-making for other parts of the marsh.
